Normal Temperature High Platform Flanged Ball Valve Q41F-16C with Manual Driving Mode

Model NO. : Q41F-16C

Driving Mode : Electric,Pneumatic,Manual

Nominal Pressure : JIS10K-20K,ANSI Class150-900,Pn1.0-32.0MPa

Channel : Straight Through Type

Structure : Floating Ball Valve

Type : Floating Ball Valve

Function : Blow-Down Valve, Relief Valve, Bypass-Valve

Temperature : Normal Temperature

Standard : JIS,ANSI,DIN,GB/T12237

Application : Industrial Usage, Water Industrial Usage, Household Usage

Transport Package : Plywood Case

Specification : CE/SGS/ISO9001

Trademark : Xuteng

Origin : China

HS Code : 8481804090

Supply Ability : 10000PCS/Week

Package Size : 140.00cm * 130.00cm * 130.00cm

Package Gross Weight : 5.000kg

Media : Oil, Water ,Gas,Acid

Material : Stainless Steel

Connection Form : Flange

Customization : Available | Customized Request

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Currency : US$

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

Place of Origin : Zhejiang China

Certification : CE/SGS/ISO9001

MOQ : 1

Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment

Price : negotiate

Contact Now

Normal Temperature High Platform Flanged Ball Valve Q41F-16C with Manual Driving Mode

The advantages of ball valve include: 1. Fast opening and closing: reduce the operation time and labor intensity.
2. Reliable sealing: good sealing performance and high reliability.
3. Full diameter design: The full diameter design of ball valve makes the internal pipeline unobstructed, flow resistance is small.
4. Good corrosion resistance: ball valve can withstand strong corrosive media.
5 Suitable for high pressure and high temperature media: ball valve in high pressure and high temperature environment stable and reliable performance.
6. Wide use: Ball valve is widely used in petroleum, chemical, pharmaceutical, light industry, textile, electric power, metallurgy and other fields.

Name	Flange floating ball valve
Model No.	Q41F-PN16
Size	DN15-DN300
Connection Form	Flange
Channel	Straight Through Type
Spool material	SS304,SS316,SS316L,304L,2205, 2507,A105,F304,F316,316L,304L,F51,F53
Stem material	2Cr13,1Cr13,17-4PH,F304,F316,F304L,F316L,F51,F53
sealing material	RPTFE,PTFE,PPL,PI,A105,F304
Filler material	PTFE,RPTFE Flexible graphite
Application	Industrial Usage
Export Markets	Global
Origin	Wenzhou, Zhejiang Province
Nominal pressure	PN16-PN100

Factory drawing:

warehouse

workshop:

Other products:

Certificate:

FAQ

Q : Are you a factory or a trading company?
A : We are a R & D factory.

Q : Which country do you export to?
A : We can export to any country according to buyer's need.

Q : Do you accept the customized order?
A : YES!

Q : What is your main market?
A : Southeast Asia, Middle East, North America, South America, Europe, etc.

Q : Can you give me a discount?
A: As you know, we are the manufacturer, so please trust us that our prices are competitive.
If the quantity is large, we can consider giving you a discount.

Q : If the product has quality problems, what will you do?
A : We will be responsible for all quality problems.

Q :What is your payment term?
A :1.T/T, 30% down payment, balance paid before shipment.
2. Letter of credit.

Q: If the product has quality problems, what will you do?
A: We will be responsible for all quality problems.
